Urethane Sheet

Urethane Sheet

Polyurethane sheeting is one of the toughest material options for polymer sheet available on the market to date. With significantly longer life spans than traditional materials such as rubber, urethane sheeting has become an industry standard for high wear applications, vibration dampening operations, die cutting materials, and a host of others. Our cast urethane sheet is completely customizable and machinable.

Advantages of Polyurethane Sheets

Versatility

Urethane is one of the most versatile polymers on the market and can be tailored to fit almost any application. Molds and formulations can be easily adjusted to create products of almost any size and hardness.

Increased Product Lifespans

Sheets made from urethane are guaranteed to last longer than traditional rubber sheets. Polyurethane does not degrade like rubber and has much higher tear resistance, abrasion resistance, thermal aging resistance, and impact resistance.

Custom Sizes

Sheet sizes can be adjusted on the fly. Moveable urethane sheet molds allow the length, width, and thickness to be adjusted without having to create new tooling. This saves the customer time and money when custom sizes are needed.

Custom Durometers

Most urethane sheeting can be produced in a wide range of durometers from 40A to 70D. Softer durometers are available for specialty applications.

Custom Formulations

Urethane can be tailored to fit end user specific requirements. Polyurethane sheets can be made using a host of different urethane compounds. Some examples include polyesters, PPG-TDI polyethers, PTMEG-TDI polyethers, FDA dry and wet food approved materials, MDIs, and high end Vulkollan equivalents.

Chemical Resistance

Urethane is known to have very good chemical resistance to grease, oils, hydrocarbons, and many solvents.

Increased Abrasion Resistance, Rebound, and Tear Strength

Polyurethane has far superior properties when compared to traditional materials like rubber. Sheet made from urethane has much better abrasion resistance, tear resistance, and rebound. This creates a product that is guaranteed to last longer and hold its shape over time without taking a set or degrading due to repeated scraping and impact.

Open Cast Urethane Sheeting

Open cast urethane sheets are the most cost-effective style of urethane sheeting available. They offer an incredible range of versatility and can be molded in practically any size, durometer, color, and formulation, including high end Vulkollan equivalents, FDA approved urethanes, polyesters, and polyethers (standard).

Uniflex Inc. is a urethane sheet manufacturer that has the capability of producing cast urethane sheeting in high and low volume production runs. We offer many standard sizes, colors, durometers, and formulations, allowing us the versatility that other urethane sheet manufacturers don’t have. Our smooth surface finish and overall product quality have become hard to match in the industry.

We offer custom formulations, sizes, and durometers upon request.

Standard Durometers (custom durometers available):

  • 50A
  • 60A
  • 70A
  • 80A
  • 90A

Standard Colors (custom colors available):

Red Green Light Blue White
Black Yellow Dark Green Brown
Blue Orange Grey Purple

Standard Sheet Sizes and Pricing (custom sizes available):

No need to request a quote on standard formulation polyurethane sheet stock. We guarantee the polyurethane sheet price in the table below for any of the standard colors and durometers. There are no setup charges. Minimum order of $100 is required. Volume price breaks are available.

Width Length Thickness
1/8″ 3/16″ 1/4″ 3/8″ 1/2″ 5/8″ 3/4″ 1″
1″ 48″ $24.00 $24.00 $24.00 $27.75 $29.85 $33.70 $37.85 $57.10
2″ 48″ $24.00 $24.00 $28.10 $31.75 $47.70 $59.35 $65.00 $79.65
3″ 48″ $31.75 $36.95 $41.95 $52.65 $63.90 $77.90 $88.35 $109.90
4″ 48″ $37.50 $44.10 $51.45 $63.80 $76.56 $91.87 $110.24 $121.27
5″ 48″ $44.90 $54.15 $63.35 $78.55 $94.26 $113.12 $135.74 $162.89
6″ 12″ $24.00 $24.00 $26.00 $31.20 $37.44 $44.93 $50.32 $60.38
18″ $24.00 $29.30 $34.28 $42.51 $51.01 $61.21 $68.56 $82.27
24″ $32.50 $36.10 $42.25 $52.39 $62.87 $75.44 $84.49 $101.39
36″ $39.75 $47.30 $52.03 $72.84 $87.41 $104.89 $117.48 $152.72
48″ $48.45 $58.95 $68.97 $89.66 $107.60 $129.11 $144.61 $202.45
12″ 12″ $32.50 $37.50 $43.88 $52.65 $64.23 $77.08 $86.33 $103.59
18″ $36.00 $47.00 $54.99 $71.49 $87.21 $104.66 $117.22 $152.38
24″ $45.25 $57.65 $68.03 $88.44 $107.89 $134.86 $155.09 $201.62
36″ $63.30 $79.00 $93.22 $121.19 $147.85 $189.24 $217.63 $282.92
48″ $77.00 $97.85 $115.46 $161.65 $197.21 $254.40 $292.56 $380.33
18″ 18″ $47.42 $59.10 $69.74 $97.63 $126.92 $152.31 $175.15 $224.20
24″ $61.70 $77.05 $90.92 $127.29 $165.47 $198.57 $228.35 $296.86
36″ $91.00 $105.95 $125.02 $175.03 $227.54 $284.42 $327.09 $425.21
48″ $107.95 $139.15 $164.20 $229.88 $298.84 $373.55 $437.05 $559.43
24″ 24″ $77.00 $98.75 $116.53 $163.14 $212.08 $254.49 $292.66 $374.61
36″ $107.95 $139.15 $164.20 $229.88 $298.84 $373.55 $433.32 $554.64
48″ $153.00 $190.65 $224.97 $326.20 $417.54 $521.92 $615.87 $788.31

Minimize Waste with Custom Urethane Sheets

Standard open cast urethane sheet can be molded in custom sizes without tooling charges. Our adjustable sheet molds allow us to produce polyurethane sheeting exactly to the dimensions you require. This eliminates excess material usage, mold tooling, and ultimately saves the customer money. Any choice of color, durometer, and formulation can be used, allowing complete versatility.

Size Capabilities

Any urethane sheet up to 48″ wide and 138″ long can be produced. Any sizes in between or up to these dimensions are accepted for production. Commonly ordered larger sheet sizes that come with discounted rates: 12″, 24″, 36″, or 48″ widths by 48″, 72″, 96″, 120″, or 138″ lengths.

Tolerances for Standard Urethane Sheet:

Thickness: +/- 0.030” for 1/8” to 3/8” and +/- 0.040” for 1/2” to 1”

Length and Width: + up to 1/2″ / – 0.000″

Need to hold a tighter tolerance on thickness?

We offer custom precision cast urethane sheets upon request. Precision cast sheets offer a precise thickness for applications that require a tighter tolerance. Our precision cast sheets are offered in a number of sizes similar to our open cast sheets as well as in the same durometers, colors, and formulations.

Precision Cast Sheets Thickness Tolerance: +/- 0.007

*All sheets come with standard width and length tolerances of + up to 0.300” and – 0.000”

Urethane Sheet Common Applications:

PU sheet (polyurethane sheet) is ideal for any industrial application where there is a tendency for high wear, impingement, sliding abrasion, impact, chemical contact, etc. Some common examples include:

  • Pads
  • Bumpers
  • Die cutting material
  • Metal forming
  • Liners
  • Cushions
  • Surface blasting applications
  • Vibration dampening
  • Energy absorption
  • Scrapers
  • Many others not listed

Common Urethane Sheet Names: Urethane plastic sheet, polyurethane rubber sheet, high density urethane sheet, pu sheet.

Have Any Questions About Urethane Sheet?

Feel free to give us a call or contact us directly through our website. We have an experienced staff that is more than willing to help you out with whatever project you are working on!
